Marine And Offshore Cables

Get a Price/Quote

Marine And Offshore Cables Specification

Impedance
Varies by cable type; specified upon request

Insulation
XLPE, EPR

Install Type
Fixed installation, tray, conduit, direct burial (on deck/shore)

Locking Type
N/A (depends on connector/fitting)

Number of Conductor
1 to 61 cores, as specified

Dielectiric Strength
3.5 kV (AC 5 min)

Armored Material
Galvanized steel wire, tinned copper wire braid, or aluminum wire armor

Core Number
2, 3, 4, 5 cores or multicore options available

Core Material
Tinned copper

Diameter
Customizable; varies by cross-section and core number

Usage & Applications
Power distribution, control circuits, signaling, communication in harsh marine environments

Tensile Strength
High tensile strength due to braided or steel wire armor

Cable Type
Flexible, Armored, Unarmored, Shielded, Multicore

Features
Flame retardant, Oil resistant, UV resistant, Halogen-free, Flexible construction, High mechanical strength, Resistant to chemicals and moisture

Conductor Shape
Stranded round, compacted, or sector shaped

Rated Temperature
-40C to +90C

Conductor Type
Flexible (Class 5/6) tinned copper

Operating Temperature
-40C to +90C continuous

Weight
Varies with size and construction

Product Type
Marine & Offshore Power/Control Cable

Length
Custom lengths available, typically 100m, 500m, 1000m rolls

Voltage
Up to 1.8/3kV, 600/1000V, or as specified

Insulation Material
Cross-linked Polyethylene (XLPE) or Ethylene Propylene Rubber (EPR)

Application
Marine and offshore installations, ships, oil rigs, offshore platforms, shipboard power and control circuits

Conductor Material
Annealed tinned copper

Jacket Material
Polyvinyl Chloride (PVC), Polyethylene (PE), or Halogen-Free Flame Retardant (HFFR)

Storage Temperature
-40C to +70C

Connector Color
Varies; generally follows international color coding for conductors

Shield Material
Tinned copper wire braid or aluminum/polyester tape

Jacket Color

Dimension (L*W*H)
Varies by cable size and specification

Color
Red outer jacket, color coded cores

Material
Copper conductor, XLPE/EPR insulation, PVC/PE/HFFR sheath

Size
0.75 mm2 to 400 mm2 and above

Seawater/Oil Resistance
Yes, designed for harsh marine and offshore conditions

Halogen Free
Available on request for low smoke/zero halogen specification

Sheath Thickness
Typically 1.8 - 3.5 mm depending on design

Rated Current
As per IEC tables, varies with size

Water Tightness
Helically overlapped metallic tape or water-blocked design upon request

UV Resistance
Excellent, suitable for outdoor/exposed environments

Minimum Bending Radius
7 to 12 times the cable outer diameter

Fire Performance
IEC 60332-1, IEC 60332-3, IEC 60754-1/2 (halogen free), IEC 61034 (smoke density)

Marine And Offshore Cables Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

Marine And Offshore Cables About

Unlock a prime level of safety and performance with our rare Marine and Offshore Cables, crafted for the most demanding environments. These redoubtable cables comply with IEC fire performance standards and offer phenomenal resistance to water, UV, oil, chemicals, and mechanical stress. Their flexible and halogen-free design ensures low smoke emission and high mechanical integrity in shipboard installations, offshore platforms, and oil rigs. Available in varied sizes, conductor types, and voltage ratings, each cable delivers reliable power supply and control where resilience is paramount.

Marine and Offshore Cables: Versatile Applications and Robust Materials

Our Marine and Offshore Cables excel in diverse application media such as ships, oil rigs, offshore platforms, and harsh marine environments. Built with flexible, high-tensile tinned copper conductors and cross-linked polyolefin or ethylene propylene rubber insulation, they showcase rare durability. Frequently used by shipbuilders, offshore contractors, and marine engineering companies, these cables stand out for their exceptional fire, oil, and UV resistance, ensuring safety and uninterrupted power in critical installations.

Delivery Time, Export Markets, and Sample Policy Details

Receive your Marine and Offshore Cables promptly, as shipping times are set according to your project quotation and location. Shipped globally, our cables enjoy robust market value in main export markets like the Middle East, Africa, and Southeast Asia. Sample cables are available on request, with our sample policy supporting accurate evaluation of quality and application fit. Connect with us today for competitive quotations tailored to your marine and offshore requirements.

FAQ's of Marine And Offshore Cables:

Q: How do Marine and Offshore Cables achieve superior fire performance?

A: These cables comply with IEC 60332-1/3 and IEC 60754-1/2 standards, combining halogen-free materials and advanced sheath designs to unlock excellent flame retardancy and low smoke emission.

Q: What are the main benefits of using these cables in offshore installations?

A: Their robust construction offers phenomenal UV, oil, water, and chemical resistance, ensuring safe and dependable operation even in the most challenging marine environments.

Q: Where are Marine and Offshore Cables typically installed?

A: They are widely used in ships, offshore platforms, oil rigs, shipboard power, control circuits, and harsh marine installations, accommodating both fixed and flexible applications.

Q: What is the process for selecting the right cable for my project?

A: Provide your technical specifications-core number, voltage, insulation type, and installation environment-and our specialists will recommend a prime solution matching your requirements.

Q: When can I expect delivery after placing an order?

A: Delivery time varies based on the size and complexity of your order, as detailed in the quotation. Standard rolls are typically shipped within a few weeks, with export timelines depending on your location.

Q: How can I obtain a sample to verify the cable's quality?

A: You can request samples as part of our sample policy. We offer these to help you confirm performance and compatibility before committing to a larger order.
