Low Voltage Cables

Get a Price/Quote

Low Voltage Cables Specification

Weight
Varies as per size and length

Core Number
Single Core, Two Core, Three Core, Four Core, Five Core, Multi-core

Operating Temperature
-10C to +70C (PVC), -10C to +90C (XLPE)

Rated Temperature
-10C to +70C (PVC) / -10C to +90C (XLPE)

Dielectiric Strength
2.5 kV for 15 min (typical)

Impedance
Varies by type; provided upon request

Conductor Type
Single or Multi-stranded

Conductor Shape
Round/Stranded or Solid as per specification

Insulation
PVC/XLPE insulation

Armored Material
Steel Wire Armored (SWA), Aluminum Wire Armored (AWA) for single core cables, or unarmored

Diameter
Depends on conductor and core size, typically 8 mm to 50 mm

Features
Flame retardant, high conductivity, durable sheath, oil and moisture resistant, long service life, high mechanical strength

Cable Type
Armored/Unarmored Low Voltage Cable

Locking Type
Not applicable to cables

Tensile Strength
High tensile strength as per IS/IEC standards, generally >12.5 N/mm2

Install Type
Suitable for underground, duct, and open installations

Core Material
Copper/Aluminum

Number of Conductor
1, 2, 3, 3.5, 4, 5, or multi-core as required

Usage & Applications
Industrial, commercial, and residential electrical wiring

Product Type
Low Voltage Cable

Length
Custom lengths available (typically from 100 meters to 1000 meters per reel)

Voltage
Up to 1100V (1.1KV)

Insulation Material
PVC, XLPE (Cross Linked Polyethylene)

Application
Power distribution, control panels, industrial installations, building wiring, indoor and outdoor use

Conductor Material
Copper, Aluminum

Jacket Material
PVC, LSZH (Low Smoke Zero Halogen) available

Storage Temperature
-20C to +60C

Connector Color
As per conductor color coding; not fixed (customizable)

Shield Material
Aluminum/Polyester tape, copper tape or unshielded

Jacket Color
Black, Grey, available as per request

Dimension (L*W*H)
Varies based on cable size and type

Color
Core colored as per standard - Red, Yellow, Blue, Black, Green/Yellow, Grey etc.

Material
Copper/Aluminum conductor, XLPE/PVC insulation, armored or unarmored

Size
1.5 sqmm to 400 sqmm and above

Halogen Free Option
Available with LSZH sheath

Short Circuit Temperature
Up to 160C (for 5 seconds for XLPE insulated)

Oxygen Index
>29% (for FRLS cables)

Bending Radius
Minimum 12 x cable diameter

Fire Performance
FR, FRLS, HR, LSZH options available

Outer Sheath Thickness
Typically 1.6mm to 4.5mm depending on cable size

Water Resistance
Available with water-blocking tape or compound upon request

UV Resistance
Available as per request for outdoor use

Flame Retardant Test
Complies with IEC 60332-1

Current Carrying Capacity
As per cable rating charts based on size and installation

Low Voltage Cables Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

Low Voltage Cables About

Redeem exceptional performance with our stellar low voltage cables, meticulously crafted for reliability and safety across a broad spectrum of installations. Boasting reserve strength with blue-ribbon flame retardant capabilities, each cable is engineered to comply with IEC 60332-1 and features halogen-free, fire-resistant, and water-blocking options. Their rare, preeminent insulation materials guarantee UV resistance, high conductivity, and a durable sheath, suitable for both indoor and outdoor applications. Available in custom lengths and myriad conductor configurations, these cables underpin preeminent energy distribution with robust mechanical and tensile strength, ensuring elite operation in industrial, commercial, or residential installations.

Versatile Application Methods & Key Features

Our low voltage cables are designed for both general and specific uses, including residential, commercial, and industrial wiring. Their robust construction supports applications in control panels, power distribution, and building wiring. Enjoy features like flame retardancy, high mechanical strength, oil and moisture resistance, and long service life. Suitable for underground, duct, or open installations, these cables can be customized in core number, insulation, and sheath to perfectly suit your unique requirements and installation environments.

Sample Policy, Quick Dispatch & Main Export Markets

Evaluate our cable quality with sample offerings, subject to prevailing rates. We prioritize quick dispatch to ensure minimal lead times on all orders. Our cables are exported to preeminent markets in Asia, the Middle East, and Africa, supporting projects of every scale. Clients can trust our commitment to punctual delivery and excellence, making us a reliable distributor, supplier, and trader across India and beyond.

FAQ's of Low Voltage Cables:

Q: How do I select the right low voltage cable for my application?

A: You should consider the installation type, required voltage, conductor material (copper or aluminum), insulation type, and sheath options. Our expert team can assist in recommending the ideal cable based on your specific needs.

Q: What is the process for ordering custom lengths or specifications?

A: Simply provide us with your detailed requirements regarding length, conductor size, insulation, and sheath preferences. We will promptly share a quote, and upon confirmation, your order will enter the production and quick dispatch queue.

Q: Where can your low voltage cables be used?

A: These cables are versatile, suitable for installation in underground ducts, open channels, residences, industrial complexes, and commercial buildings, either for power distribution or control panel wiring.

Q: What are the key benefits of using flame retardant and LSZH cables?

A: Flame retardant and LSZH cables enhance fire safety and minimize toxic smoke emission, making them ideal for public spaces and enclosed areas where safety and air quality are priorities.

Q: When can I expect delivery after placing an order?

A: Delivery timelines depend on the cable specifications and quantities ordered, but we ensure quick dispatch with prompt shipment updates to meet project deadlines efficiently.
