Fire Survival - Resistant Cables

Get a Price/Quote

Fire Survival - Resistant Cables Specification

Install Type
Indoor/Outdoor, fixed and conduit installation

Usage & Applications
Critical power and control circuits for fire alarm, sprinkler, and emergency systems

Dielectiric Strength
3.5 kV for 5 minutes

Rated Temperature
Up to 950C under fire condition (PH120)

Tensile Strength
High, as per IEC/IS standards

Armored Material
Galvanized Steel Wire/Strip

Impedance
As per IEC/IS standards

Number of Conductor
Single core, 2 core, 3 core, 4 core, multi core

Diameter
Depends on size and number of cores

Weight
Varies with size and core configuration

Core Material
Electrolytic Copper or Aluminum

Features
Fire survival, flame resistant, low smoke emission, halogen-free, maintains circuit integrity during fire

Core Number
1 to 4 (other configurations available)

Conductor Shape
Round

Conductor Type
Stranded or Solid

Operating Temperature
-40C to +90C

Insulation
Mica Tape + XLPE

Cable Type
Fire Survival/Resistant Power Cable

Product Type
Fire Survival - Resistant Cable

Length
Available in custom lengths as per requirement

Voltage
Up to 1100V

Insulation Material
Mica Glass Tape + XLPE (Cross-Linked Polyethylene)

Application
Power distribution, emergency circuits, fire alarm systems, smoke extraction fans, emergency lighting, safety circuits

Conductor Material
Annealed Copper or Aluminum

Jacket Material
LSZH (Low Smoke Zero Halogen)

Storage Temperature
-15C to +70C

Shield Material
Aluminum Mylar Tape + Copper Drain Wire (optional)

Jacket Color
Black or as specified

Dimension (L*W*H)
As per order, custom sizes available

Color
Black, Red, Blue, Grey, Green (as specified)

Material
Copper/Aluminum with LSZH, XLPE, Mica Glass insulation

Size
1.5 sqmm to 400 sqmm (custom as required)

Smoke Emission
Low smoke conforming to IEC 61034

Max Bending Radius
12 x cable outer diameter

Sheath Marking
Manufacturer's details, voltage rating, fire survival rating

Outer Diameter Range
Varies from 10mm to 80mm (as per size and cores)

UV Resistance
Yes, suitable for outdoor use

Circuit Integrity
120 minutes at 950C (PH120 rating)

Halogen Index
Zero Halogen, <0.5% as per IEC 60754-1

Resistance to Acids & Alkalis
Good, suitable for industrial environment

Flame Retardant Test
Passes IEC 60332-1 and IEC 60332-3

Fire Survival - Resistant Cables Trade Information

Minimum Order Quantity
100 Meter

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

Fire Survival - Resistant Cables About

Ending Soon-Secure your critical infrastructure with our Fire Survival - Resistant Cables, engineered for monumental protection and rarefied safety. With instant checkout, acquire cables highlighted by low smoke emission, zero halogen, and PH120 rating to ensure imposing circuit integrity for 120 minutes under fire at 950C. UV and acid-resistant, these cables perform reliably outdoors and in severe industrial environments. Customizable dimensions and construction (1.5-400 sqmm, multi-core) meet the most exacting requirements. Don't miss this opportunity for rare, premium fire-resistant power.

Versatile Application & Installation

These fire survival-resistant cables are expertly designed for high-stake environments, including emergency lighting, fire alarm circuits, smoke extraction fans, and safety-critical power distribution. Their application methods support fixed and conduit installations, both indoors and outdoors. Suitable for commercial buildings, industrial complexes, and hazardous zones, they maintain robust performance even amid fire, ensuring uninterrupted operation of life-saving systems during emergencies.

Flexible Payment & Reliable Shipping

We offer premium, tailored payment terms designed for convenience. Goods are shipped promptly from our main domestic market in India, with FOB ports ensuring streamlined logistics and secure delivery. Every order, regardless of size or customization, is handled with utmost priority, guaranteeing safe receipt of your fire survival cables with minimal lead times. Choose confidence and quality in every transaction for your urgent safety needs.

FAQ's of Fire Survival - Resistant Cables:

Q: How do fire survival-resistant cables ensure safety during a fire?

A: These cables are engineered to maintain circuit integrity for up to 120 minutes at 950C (PH120), ensuring connected safety systems like alarms and lighting remain operational during fire incidents.

Q: What standards do these cables comply with for fire resistance and low smoke emission?

A: They conform to IEC 61034 (low smoke), IEC 60754-1 (zero halogen), and pass flame retardant tests IEC 60332-1 & 60332-3, offering advanced protection in hazardous conditions.

Q: When should I use fire survival-resistant cables over standard cables?

A: Use these cables wherever safety-critical circuits are present, such as emergency lighting, power distribution for safety systems, fire alarms, and smoke extraction fans in commercial or industrial buildings.

Q: Where can these cables be installed?

A: They are suitable for both indoor and outdoor installations, including fixed and conduit setups in harsh environments, thanks to their UV, acid, and alkali resistance.

Q: What is the process for customizing cable specifications and placing orders?

A: Contact the supplier with your required voltage, length, core configuration, and color. Orders are tailored to your specifications, ensuring optimal fit for unique project demands.

Q: What benefits do these cables offer in industrial and critical safety applications?

A: They provide monumental fire resistance, low smoke, halogen-free safety, UV protection, and high mechanical strength, ensuring reliable operation in emergencies and compliance with stringent safety codes.
